Build a tree by making one useful split at a time.

This page starts with a tiny classification problem, then turns it into a hands-on lesson about entropy, information gain, and why a tree that keeps chasing perfect purity can stop generalizing.

Play with split building Inspect entropy and gain See why single trees wobble
How to use this page

Start by jumping straight to the entropy sandbox or by scrolling through the first tree build. Watch the partition chart and the tree diagram together, then come back to the gain and perturbation sections once the split logic feels intuitive.

Play first: entropy sandbox Start the split story

Decision Trees

The unreasonable power of nested decision rules.

Let's Build a Decision Tree

Let's pretend we're farmers with a new plot of land. Given only the Diameter and Height of a tree trunk, we must determine if it's an Apple, Cherry, or Oak tree. To do this, we'll use a Decision Tree.

Start Splitting

Almost every tree with a Diameter ≥ 0.45 is an Oak tree! Thus, we can probably assume that any other trees we find in that region will also be one.

This first decision node will act as our root node. We'll draw a vertical line at this Diameter and classify everything above it as Oak (our first leaf node), and continue to partition our remaining data on the left.

Split Some More

We continue along, hoping to split our plot of land in the most favorable manner. We see that creating a new decision node at Height ≤ 4.88 leads to a nice section of Cherry trees, so we partition our data there.

Our Decision Tree updates accordingly, adding a new leaf node for Cherry.

And Some More

After this second split we're left with an area containing many Apple and some Cherry trees. No problem: a vertical division can be drawn to separate the Apple trees a bit better.

Once again, our Decision Tree updates accordingly.

And Yet Some More

The remaining region just needs a further horizontal division and boom - our job is done! We've obtained an optimal set of nested decisions.

That said, some regions still enclose a few misclassified points. Should we continue splitting, partitioning into smaller sections?

Hmm...

Don't Go Too Deep!

If we do, the resulting regions would start becoming increasingly complex, and our tree would become unreasonably deep. Such a Decision Tree would learn too much from the noise of the training examples and not enough generalizable rules.

That is the classic bias-variance tradeoff in action. In this case, going too deep results in a tree that overfits our data, so we'll stop here.

We're done! We can simply pass any new data point's Height and Diameter values through the newly created Decision Tree to classify them as either an Apple, Cherry, or Oak tree!

Where To Partition?

We just saw how a Decision Tree operates at a high-level: from the top down, it creates a series of sequential rules that split the data into well-separated regions for classification. But given the large number of potential options, how exactly does the algorithm determine where to partition the data? Before we learn how that works, we need to understand Entropy.

Entropy measures the amount of information of some variable or event. We'll make use of it to identify regions consisting of a large number of similar (pure) or dissimilar (impure) elements.

Given a certain set of events that occur with probabilities , the total entropy can be written as the negative sum of weighted probabilities:

The quantity has a number of interesting properties:

Entropy Properties

  1. only if all but one of the are zero, this one having the value of 1. Thus the entropy vanishes only when there is no uncertainty in the outcome, meaning that the sample is completely unsurprising.
  2. is maximum when all the are equal. This is the most uncertain, or "impure", situation.
  3. Any change towards the equalization of the probabilities increases .

The entropy can be used to quantify the impurity of a collection of labeled data points: a node containing multiple classes is impure whereas a node including only one class is pure.

Above, you can compute the entropy of a collection of labeled data points belonging to two classes, which is typical for binary classification problems. Click on the Add and Remove buttons to modify the composition of the bubble.

Did you notice that pure samples have zero entropy whereas impure ones have larger entropy values? This is what entropy is doing for us: measuring how pure (or impure) a set of samples is. We'll use it in the algorithm to train Decision Trees by defining the Information Gain.

Information Gain

With the intuition gained with the above animation, we can now describe the logic to train Decision Trees. As the name implies, information gain measures an amount the information that we gain. It does so using entropy. The idea is to subtract from the entropy of our data before the split the entropy of each possible partition thereafter. We then select the split that yields the largest reduction in entropy, or equivalently, the largest increase in information.

The core algorithm to calculate information gain is called ID3. It's a recursive procedure that starts from the root node of the tree and iterates top-down on all non-leaf branches in a greedy manner, calculating at each depth the difference in entropy:

To be specific, the algorithm's steps are as follows:

ID3 Algorithm Steps

  1. Calculate the entropy associated to every feature of the data set.
  2. Partition the data set into subsets using different features and cutoff values. For each, compute the information gain as the difference in entropy before and after the split using the formula above. For the total entropy of all children nodes after the split, use the weighted average taking into account , i.e. how many of the samples end up on each child branch.
  3. Identify the partition that leads to the maximum information gain. Create a decision node on that feature and split value.
  4. When no further splits can be done on a subset, create a leaf node and label it with the most common class of the data points within it if doing classification or with the average value if doing regression.
  5. Recurse on all subsets. Recursion stops if after a split all elements in a child node are of the same type. Additional stopping conditions may be imposed, such as requiring a minimum number of samples per leaf to continue splitting, or finishing when the trained tree has reached a given maximum depth.

Of course, reading the steps of an algorithm isn't always the most intuitive thing. To make things easier to understand, let's revisit how information gain was used to determine the first decision node in our tree.

Recall our first decision node split on Diameter ≤ 0.45. How did we choose this condition? It was the result of maximizing information gain.

Each of the possible splits of the data on its two features (Diameter and Height) and cutoff values yields a different value of the information gain.

The line chart displays the different split values for the Diameter feature. Move the decision boundary yourself to see how the data points in the top chart are assigned to the left or right children nodes accordingly. On the bottom you can see the corresponding entropy values of both children nodes as well as the total information gain.

The ID3 algorithm will select the split point with the largest information gain, shown as the peak of the black line in the bottom chart of 0.574 at Diameter = 0.45.

Recall our first decision node split on Diameter ≤ 0.45. How did we choose this condition? It was the result of maximizing information gain.

Each of the possible splits of the data on its two features (Diameter and Height) and cutoff values yields a different value of the information gain.

The visualization on the right allows to try different split values for the Diameter feature. Move the decision boundary yourself to see how the data points in the top chart are assigned to the left or right children nodes accordingly. On the bottom you can see the corresponding entropy values of both children nodes as well as the total information gain.

The ID3 algorithm will select the split point with the largest information gain, shown as the peak of the black line in the bottom chart of 0.574 at Diameter = 0.45.

A Note On Information Measures

An alternative to the entropy for the construction of Decision Trees is the Gini impurity. This quantity is also a measure of information and can be seen as a variation of Shannon's entropy. Decision trees trained using entropy or Gini impurity are comparable, and only in a few cases do results differ considerably. In the case of imbalanced data sets, entropy might be more prudent. Yet Gini might train faster as it does not make use of logarithms.

Why this matters

The splitter is greedy on purpose: it only asks which cut improves impurity the most right now. That makes trees fast and interpretable, but it also means later branches inherit every early choice.

Another Look At Our Decision Tree

Let's recap what we've learned so far. First, we saw how a Decision Tree classifies data by repeatedly partitioning the feature space into regions according to some conditional series of rules. Second, we learned about entropy, a popular metric used to measure the purity (or lack thereof) of a given sample of data. Third, we learned how Decision Trees use entropy in information gain and the ID3 algorithm to determine the exact conditional series of rules to select. Taken together, the three sections detail the typical Decision Tree algorithm.

To reinforce concepts, let's look at our Decision Tree from a slightly different perspective.

The tree below maps exactly to the tree we showed in How to Build a Decision Tree section above. However, instead of showing the partitioned feature space alongside our tree's structure, let's look at the partitioned data points and their corresponding entropy at each node itself:


From the top down, our sample of data points to classify shrinks as it gets partitioned to different decision and leaf nodes. In this manner, we could trace the full path taken by a training data point if we so desired. Note also that not every leaf node is pure: as discussed previously (and in the next section), we don't want the structure of our Decision Trees to be too deep, as such a model likely won't generalize well to unseen data.

The Problem of Pertubations

Without question, Decision Trees have a lot of things going for them. They're simple models that are easy to interpret. They're fast to train and require minimal data preprocessing. And they handle outliers with ease. Yet they suffer from a major limitation, and that is their instability compared with other predictors. They can be extremely sensitive to small perturbations in the data: a minor change in the training examples can result in a drastic change in the structure of the Decision Tree.

Check for yourself how small random Gaussian perturbations on just 5% of the training examples create a set of completely different Decision Trees:



Why Is This A Problem?

In their vanilla form, Decision Trees are unstable.

If left unchecked, the ID3 algorithm to train Decision Trees will work endlessly to minimize entropy. It will continue splitting the data until all leaf nodes are completely pure - that is, consisting of only one class. Such a process may yield very deep and complex Decision Trees. In addition, we just saw that Decision Trees are subject to high variance when exposed to small perturbations of the training data.

Both issues are undesirable, as they lead to predictors that fail to clearly distinguish between persistent and random patterns in the data, a problem known as overfitting. This is problematic because it means that our model won't perform well when exposed to new data.

There are ways to prevent excessive growth of Decision Trees by pruning them, for instance constraining their maximum depth, limiting the number of leaves that can be created, or setting a minimum size for the amount of items in each leaf and not allowing leaves with too few items in them.

As for the issue of high variance? Well, unfortunately it's an intrinsic characteristic when training a single Decision Tree.

The Need to Go Beyond Decision Trees

Perhaps ironically, one way to alleviate the instability induced by perturbations is to introduce an extra layer of randomness in the training process. In practice this can be achieved by creating collections of Decision Trees trained on slightly different versions of the data set, the combined predictions of which do not suffer so heavily from high variance. This approach opens the door to one of the most successful Machine Learning algorithms thus far: random forests.

Continue to the local Random Forest explainer.

The End

Thanks for reading. The walkthrough above keeps the full decision-tree story intact, including the split-building progression, entropy sandbox, information-gain view, and perturbed-tree comparisons.

To keep things compact, it skips over related topics such as regression trees, end-cut preference, and additional tree-specific hyperparameters. The references below are still part of the lesson and are useful for going deeper.
